FC 1410 Shock Absorber

FC 1410 Shock Absorber
FC 1410 Shock Absorber
Send Inquiry
Product Code : FC 1410
Brand Name : CEC YUH BAW CO., LTD.
Product Description

FC 1410 Shock Absorber

We are counted as one of the leaders in the industry, engaged in manufacturing and exporting a technically advanced range of FC 1410 Shock Absorber. We use the highest grade materials and core techniques in the manufacturing of these absorbers, as per the standards laid down by regulatory bodies. Our FC 1410 Shock Absorber effectively absorb high shock impulses etc. We lay prime emphasis on the packaging of these products to ensure safe delivery at client's end.

Features:

  • Well known for characteristics like less maintenance, corrosion resistance and high load bearing strength
  • Very short overall length and low return force
  • Can be customized according to load and speed requirements

Technical Specification:

  • M14X1.5P/M14X1.0P
  • Cross Flat B=19 (C=21.6)

Model

Stroke (mm)

Max NM Per Cycle (mm)

Effective weight we (kg)

Max Impact Speed

Max NM Per Hour

Return Force N

ÂșC Temperature

FC 1410

10

15

2.9 ~ 120

3.2

27,000

5 ~ 12

-10 ~ 70
