SC 1425 NC Shock Absorbers

Name: SC 1425 NC Shock Absorbers
Brand: CEC YUH BAW CO., LTD.
Price: 26.4 USD
Availability: InStock

Price 26.4 USD ($)/ Piece

Get a Price/Quote

MOQ : 1 Piece

SC 1425 NC Shock Absorbers Specification

Weight
(Approx.) 2.5 Kilograms (kg)

Product Type
Shock Absorber

Usage
Industrial

Position
Front and Rear

Spring Material
Steel

Size
Different Sizes Available

Spring Type
Coil Spring

Color
Black

Body Material
Alloy Steel

Thread Size
M14 x 1.5

Mounting Type
Screw Mount

Damping Force
Adjustable

Maximum Stroke
25 mm

Model Number
SC 1425 NC

Outer Diameter
14 mm

SC 1425 NC Shock Absorbers Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
10000 Pieces Per Month

Delivery Time
30 Days

SC 1425 NC Shock Absorbers About

Relying upon our highly advanced infrastructural unit, we are able to manufacture, export and supply quality checkedSC 1425 NC Shock Absorbers. Customers extensively use the offered absorbers in industrial machines for self compensating the shocks to ensure hassle free performance. Using the best grade raw materials and sophisticated techniques, these absorbers are manufactured with the help of dexterous professionals. Additionally, the providedSC 1425 NC Shock Absorberscan be bought from us in various impact speeds and effective weights of 28 mm stroke length at the most economical prices.

Key points:

Easy installation
High durability
Seamless cross flat finish
Excellent strength

SC 1425 NC SHOCK ABSORBERS

Technical specification:

M14X1.5P/ M14X1.0P
Cross Flat B=19 (C=21.6)

SC 1425 1 NC	25	28	4.6 25	3.5	58800	-10 70
SC 1425 2 NC	25	28	14 87.5	2.0	58800	-10 70
SC 1425 3 NC	25	28	25 350	1.5	58800	-10 70

Precision Adjustable Damping

The SC 1425 NC Shock Absorber features adjustable damping force, allowing for tailored operation according to specific industrial needs. This capability enhances performance and extends equipment life by effectively absorbing impacts. The robust alloy steel construction ensures resistance to wear even in demanding environments.

Versatile Industrial Compatibility

Engineered for various industrial sectors, this shock absorber can be integrated into machinery requiring controlled motion and vibration reduction. The screw mount offers ease of installation, while the M14 x 1.5 thread size guarantees compatibility with a range of setups, making it a flexible solution for diverse industries.

Reliable Build and Sizing Options

Crafted with an alloy steel body and steel spring, the SC 1425 NC delivers high durability and reliability. Its availability in different sizes ensures it meets various application requirements, supporting distributors and users in selecting the right fit for their machinery.

FAQs of SC 1425 NC Shock Absorbers:

Q: How do I adjust the damping force on the SC 1425 NC Shock Absorber?

A: You can adjust the damping force by turning the adjustment knob or screw, allowing you to fine-tune the shock absorber according to the applications load and motion requirements.

Q: What are the primary applications of the SC 1425 NC Shock Absorber?

A: This shock absorber is primarily used in industrial machinery where controlled motion, impact absorption, and vibration reduction are essential for smooth operation and equipment longevity.

Q: When should I consider replacing or servicing the SC 1425 NC Shock Absorber?

A: It is advisable to inspect and service or replace the shock absorber when you notice changes in damping performance, visible wear, or if the equipment does not return to optimal operation after adjustment.

Q: Where can I purchase or source the SC 1425 NC Shock Absorber in Taiwan?

A: You can acquire the SC 1425 NC Shock Absorber from authorized distributors, exporters, importers, manufacturers, suppliers, and traders throughout Taiwan.

Q: What is the typical installation process for the SC 1425 NC Shock Absorber?

A: Installation is straightforward due to the screw mount design and standard M14 x 1.5 thread size. Position the absorber in the designated mount and secure it using appropriate tools, ensuring it is firmly in place.

Q: How does using this shock absorber benefit industrial machinery?

A: The SC 1425 NC minimizes machine downtime and maintenance costs by efficiently absorbing shocks and vibrations, thereby improving the life and performance of critical equipment.
